Low lift high flow centrifugal diesel agricultural pump

Self-Priming Pump

Shaft power : 2.5Kw-170Kw Equipped with power : 3Kw-180Kw
Flow : 0m³/h-7200m³/h Head :0m-20m

Chat Now Inquiry Now Add to My Favorite List Download Catalog

Product Details
50Hz product parameter
60Hz product parameter
Videos
Q&A

Product Description
1.Purpose: HW-S type mixed flow pump is a horizontal, single-stage, single-suction, front and rear door-opening structure, cantilever type mixed flow pump. It is suitable fo transporting clean water or other liquids with physical and chemical properties similar to water. The temperature of the transported liquid should not be higher than 50°C. Iti widely used in farmland drainage and irrigation, industrial and urban water supply and drainage and other occasions. Performance range of HW-S type mixed flow pump:Flow: 50-4500 meters/hourLift: 3-20 meters.

2. Features: simple structure, reliable use, easy assembly and disassembly, small size light weight, large flow rate and high efficiency.

3. Transmission mode: There are two types: direct transmission and belt transmission. Commonly used power machines are electric motors and diesel engines. When ordering, the model (power, speed) of the power machine should be specified in order to determine the specifications of the pulley or coupling.

4. Water pump steering: Viewed from the water pump inlet, the impeller rotates counterclockwise (650HW-7S rotates clockwise).5. Model description: Take 300HW-7S as an example:300-pump inlet and outlet diameter. Unit: mm HW-horizontal volute mixed flow pump. 7 is the design lift. Unit. mS—structural form (front and rear door opening structure).6. The standard HW-S type pump is designed, manufactured and accepted according to GB/T13008 and JB/T6667 standards.
HW-S Type Mixed Flow Pump

We have ISO, CE, CCCF, CB certificates, and we are preparing for UL at present. And we can make certificates like PVOC, PCOC, and SONCAP to help our clients with clearance. YesChamp is advanced Low lift high flow centrifugal diesel agricultural pump suppliers and wholesale Low lift high flow centrifugal diesel agricultural pump manufacturers, have been export to more than 60 countries with competitive price. OEM/ODM order? Pls contact us for design details, and we will quote you reasonable prices and make samples for you ASAP. We have R&D team.
